POLARIS OUTLAW 525 S [2007-2011] - WÖSSNER Pro Series forged pistons

WÖSSNER Pro Series forged pistons for the Polaris Outlaw 525 S

The WÖSSNER Pro Series forged piston is designed for the Polaris Outlaw 525 S from the 2007-2011 model year range. As a component for the upper engine area, it combines a forged design with high-compression piston compression and is suitable for the targeted renewal of the piston within this vehicle classification.

Function and execution

The piston is made of aluminum and has a forged double bridge. The design with a compression ratio of 12.5:1 describes the intended piston compression. Two rings are part of the technical design of the piston.

Technical data

• Brand: WOSSNER
• Piston Type: Forged
• Material: aluminum
• Piston compression: high compression
• Diameter Ø: 94.95 mm
• Letter oversize: A
• Oversize: STD
• Bore diameter: 95.00 mm
• Compression ratio: 12.5:1
• Number of rings: 2
• Stroke: 4T
• Specificity: Forged double bridge

Vehicle assignment

The WÖSSNER Pro Series forged piston is assigned to the Polaris Outlaw 525 S in the full year range 2007-2011. The information on diameter Ø, bore diameter, letter oversize and oversize support the selection of the appropriate piston for this application.
