Yamaha T-MAX 530 (SJ 09) [2012-2016] - WÖSSNER forged pistons

WÖSSNER forged pistons for Yamaha T-MAX 530

The forged WÖSSNER piston is designed for the Yamaha T-MAX 530 (SJ 09) from the 2012-2016 model year range. Its aluminum design combines the documented forged construction with an anti-friction coated piston skirt.

Function and execution

The piston is designed with standard piston compression. The coating on the shaft supports a low-friction design within the intended engine components. Wössner forged pistons are manufactured in Germany by specialists in 2- and 4-stroke engine parts.

Technical data

• Material: aluminum
• Piston Type: Forged
• Piston compression: standard
• Diameter Ø: 69.95 mm
• Letter oversize: 200
• Oversize: +2.00
• Bore diameter: 70.00 mm
• Compression ratio: 10.0:1

Vehicle allocation and delivery

The vehicle assignment applies to the Yamaha T-MAX 530 (SJ 09), built between 2012 and 2016. The forged piston is delivered with ring(s), locking ring(s) and axle.

The specified dimensions and the marking of the oversize make it easier to select the right piston for the specified vehicle version.
